78 ProScreen
Design For Buckets Up To 82 inches
1 / 10
DESIGNED FOR MID SIZE EQUIPMENT
COMPACT WHEEL LOADER
MINI EXCAVATOR
YOU CAN SCREEN
FEATURES
FEED DEFLECTION SYSTEM + FLOW CONTROL WINGS
The FEED DEFLECTION SYSTEM combined with FLOW CONTROL wings is designed to ensure more uniform screening of materials in process. These systems enable material to enter the screener evenly, optimizing the efficiency of the operation. The FLOW CONTROL wings, unique and exclusive to the 78 ProScreen model, play a crucial role in controlling the flow of material, allowing larger particles like stones and other objects to pass through smoothly. These wings are adjustable, accommodating different material sizes, and then returning to their original position, ensuring consistent performance.
1 / 4
MACHINE SPECIFICATIONS
MACHINE DIMENSIONS
Machine Width
98 inches
Machine Height
104 inches
Machine Depth
72 inches
SCREEN DECK
Screen Deck Width
80 inches
Screen Deck Length
52 inches
Screen Deck Surface area
29 sq/ft
Screen Deck Tilt Angle
45 to 30 Degrees
VIBRATORY SYSTEM
Vibratory Style System
Dual Eccentric Armature
Eccentric Rotation Speed
3600 rpm
Amperage Draw
10 each on start up with 5 Amps Amp draw per motor at 3600rpm
Eccentric Force rotation
760 lbs per/revolution
ELECTRICAL POWER SUPPLY
North America
110 Volt ( 60 Hertz )
WEIGHT
Total Weight with riser box
2500 lbs
Total Weight without riser box
2000 lbs
5 Year Structural Warranty
1 Year Electrical Warranty
MESH AVAILABLE
SQUARE
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 5/32" x 5/32" | Square | 1/16" |
| 1/4" x 1/4" | Square | 1/8" |
| 3/8" x 3/8" | Square | 1/4" |
| 1/2" x 1/2" | Square | 3/8" |
| 1" x 1" | Square | 3/4" |
| 2" x 2" | Square | 1-1/2" |
| 3" x 3" | Square | 2" |
| 4" x 4" | Square | 3" |
ELONGATED
| Mesh Size | Pattern | Product Size |
|---|---|---|
| 3/8" x 4" | Elongated | 1/4" to 5/16" |
| 1/2" x 4" | Elongated | 3/8" to 7/16" |
| 3/4" x 4" | Elongated | 1/2" to 9/16" |
| 1" x 4" | Elongated | 3/4" to 7/8" |
